Specifications
Broad Compatibility
Alva Link seamlessly connects with a wide and increasing range of energy products, including heat pumps, inverters, and smart meter readers.
Multiple energy products can be connected to the same Alva Link.
Easy Connectivity
Connects to your home network via Wi-Fi (2.4 GHz) and uses BLE 4.2 or later for initial setup.
An internet connection is required for price- and weather based optimisation.
Smart Home Compatibility
Integrates with popular smart home systems like Homey and Home Assistant.
Matter support is planned.
Dimensions & Mounting
- Dimensions: 150mm x 70mm x 45mm (HxBxD)
- Weight: 275 grams
- Mounting: Easily wall-mounted with included adhesive pads or screws (not included).
Power supply
USB-C (5W /Â 1A minumum)
Protocol support
- Modbus TCP - enables digital communication over an Ethernet (RJ45) connection.
- Modbus RTU -
Provides serial communication via the Modbus RTU protocol over an RS-485 bus.
- SG Ready - Smart Grid Ready dry contacts for supported heat pumps (30V 100mA max)
- Temperature “override” mode - override outdoor temperature sensor to boost/block heating

Easy to Get Started
1
Plug in Alva Link

Plug in Alva Link and connect it to your heat pump, home battery, or solar inverter —done in minutes
⚡Need help? We partner with electricians nationwide.
2
Our app guides you

Select your devices in the Alva App and configure the system in minutes with our guides.
3
Start saving

From day one, Alva Link optimises your energy use — fully automatic, fully safe.
